import duckdb
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
import plotly.express as px
import plotly.io as pio

pio.renderers.default = "notebook_connected"

# Configuration
pd.set_option('display.max_columns', None)
sns.set(style="whitegrid")

# Connect to DuckDB
con = duckdb.connect()

# File path
base_path = "./data/raw/"

files = {
    "cdc": base_path + "diabetes_012_health_indicators_BRFSS2023.csv",
    "idf": base_path + "idf_south_central_america_formatted.csv",
    "paho_prevalence": base_path + "paho_prevalence_trends.csv",
    "paho_burden": base_path + "paho_burden_2019.csv",
    "paho_deaths_country": base_path + "paho_level_by_country.csv",
    "paho_summary": base_path + "paho_diabetes_in_the_americas_summary_of_estimates.csv"
}

# Load all tables
for name, path in files.items():
    con.execute(f"""
        CREATE OR REPLACE TABLE {name} AS
        SELECT * FROM read_csv_auto('{path}')
    """)
    print(f"Table '{name}' loaded.")

# Function to check basic info
def quick_check(table_name):
    print(f"\n=== {table_name.upper()} ===")
    count = con.execute(f"SELECT COUNT(*) AS rows FROM {table_name}").fetchone()[0]
    print(f"Rows: {count:,}")
    print("\nColumns:")
    cols = con.execute(f"DESCRIBE {table_name}").fetchdf()
    print(cols[['column_name', 'column_type']])
    print("\nFirst 3 rows:")
    print(con.execute(f"SELECT * FROM {table_name} LIMIT 3").fetchdf())

# Verify all tables
for name in files.keys():
    quick_check(name)

# Quick view of CDC target
print("\nDiabetes_012 (CDC): Distribution")
print(con.execute("""
    SELECT Diabetes_012, COUNT(*) AS count,
           ROUND(COUNT(*) * 100.0 / SUM(COUNT(*)) OVER (), 2) AS percentage
    FROM cdc
    GROUP BY Diabetes_012
    ORDER BY Diabetes_012
""").fetchdf())

Table 'cdc' loaded.
Table 'idf' loaded.
Table 'paho_prevalence' loaded.
Table 'paho_burden' loaded.
Table 'paho_deaths_country' loaded.
Table 'paho_summary' loaded.

=== CDC ===
Rows: 261,589

Columns:
             column_name column_type
0           Diabetes_012      DOUBLE
1          KidneyDisease      DOUBLE
2                 HighBP      DOUBLE
3               HighChol      DOUBLE
4              CholCheck      DOUBLE
5                 Asthma      DOUBLE
6                   COPD      DOUBLE
7                    BMI      DOUBLE
8                 Smoker      DOUBLE
9                 Stroke      DOUBLE
10  HeartDiseaseorAttack      DOUBLE
11          PhysActivity      DOUBLE
12     HvyAlcoholConsump      DOUBLE
13         AnyHealthcare      DOUBLE
14           NoDocbcCost      DOUBLE
15               GenHlth      DOUBLE
16              MentHlth      DOUBLE
17              PhysHlth      DOUBLE
18              DiffWalk      DOUBLE
19                   Sex      DOUBLE
20              AgeGroup      DOUBLE
21             Education      DOUBLE
22                Income      DOUBLE

First 3 rows:
   Diabetes_012  KidneyDisease  HighBP  HighChol  CholCheck  Asthma  COPD  \
0           0.0            2.0     1.0       1.0        1.0     1.0   2.0
1           2.0            2.0     1.0       0.0        1.0     2.0   2.0
2           0.0            2.0     1.0       1.0        1.0     2.0   2.0

    BMI  Smoker  Stroke  HeartDiseaseorAttack  PhysActivity  \
0  22.0     1.0     0.0                   0.0           1.0
1  26.0     0.0     0.0                   0.0           1.0
2  30.0     0.0     0.0                   0.0           1.0

   HvyAlcoholConsump  AnyHealthcare  NoDocbcCost  GenHlth  MentHlth  PhysHlth  \
0                0.0            1.0          1.0      4.0       2.0       6.0
1                0.0            1.0          0.0      4.0       0.0       0.0
2                0.0            1.0          0.0      3.0       3.0       2.0

   DiffWalk  Sex  AgeGroup  Education  Income
0       1.0  0.0      13.0        4.0     2.0
1       1.0  0.0      12.0        5.0     7.0
2       0.0  0.0       9.0        5.0     7.0

=== IDF ===
Rows: 88

Columns:
  column_name column_type
0    Category     VARCHAR
1      Metric     VARCHAR
2        Year      BIGINT
3       Value      DOUBLE

First 3 rows:
                       Category  \
0  Diabetes estimates (20-79 y)
1  Diabetes estimates (20-79 y)
2  Diabetes estimates (20-79 y)

                                              Metric  Year   Value
0                    People with diabetes, in 1,000s  2000  8553.3
1         Age-standardised prevalence of diabetes, %  2000     3.7
2  Proportion of people with undiagnosed diabetes, %  2000     NaN

=== PAHO_PREVALENCE ===
Rows: 180

Columns:
         column_name column_type
0      Location Code     VARCHAR
1   Location Name En     VARCHAR
2  Indicator Name En     VARCHAR
3       Age Group En     VARCHAR
4             Sex En     VARCHAR
5               Year      BIGINT
6              Value     VARCHAR
7          Value Low     VARCHAR
8         Value High     VARCHAR

First 3 rows:
  Location Code        Location Name En  \
0           AMR  Region of the Americas
1           AMR  Region of the Americas
2           AMR  Region of the Americas

                                   Indicator Name En Age Group En      Sex En  \
0  Diabetes treatment coverage (current use of gl...    30+ years  Both sexes
1  Diabetes treatment coverage (current use of gl...    30+ years  Both sexes
2  Diabetes treatment coverage (current use of gl...    30+ years  Both sexes

   Year   Value Value Low Value High
0  1990  42.47%    38.20%     46.90%
1  1995  44.62%    41.00%     48.20%
2  2000  46.60%    43.80%     49.50%

=== PAHO_BURDEN ===
Rows: 120

Columns:
        column_name column_type
0              Iso3     VARCHAR
1     Location Name     VARCHAR
2   AMRO subregions     VARCHAR
3     Causename Eng     VARCHAR
4              Year      BIGINT
5               Sex     VARCHAR
6         Age group     VARCHAR
7   Measure Name En     VARCHAR
8    Metric Name En     VARCHAR
9             Value     VARCHAR
10        Value Low     VARCHAR
11         Value Up     VARCHAR

First 3 rows:
   Iso3           Location Name         AMRO subregions  \
0  AMRO  Region of the Americas  Region of the Americas
1  AMRO  Region of the Americas  Region of the Americas
2  AMRO  Region of the Americas  Region of the Americas

                                       Causename Eng  Year         Sex  \
0  Diabetes mellitus (excluding CKD due to Diabetes)  2019  Both sexes
1  Diabetes mellitus (excluding CKD due to Diabetes)  2019  Both sexes
2  Diabetes mellitus (excluding CKD due to Diabetes)  2019  Both sexes

          Age group                         Measure Name En Metric Name En  \
0  Age-standardized                                  Deaths           Rate
1  Age-standardized  Disability-Adjusted Life Years (DALYs)           Rate
2  Age-standardized      Years Lived with Disability (YLDs)           Rate

      Value Value Low  Value Up
0     19.64     17.26     22.02
1  1,119.49    866.64  1,423.70
2    604.86     408.1    847.76

=== PAHO_DEATHS_COUNTRY ===
Rows: 35

Columns:
              column_name column_type
0                    Iso3     VARCHAR
1       Quintiles classes     VARCHAR
2           Causename Eng     VARCHAR
3           Location Name     VARCHAR
4         Measure Name En     VARCHAR
5                    Year      BIGINT
6    Latitude (generated)      DOUBLE
7   Longitude (generated)      DOUBLE
8               Value Low      DOUBLE
9                Value Up      DOUBLE
10                  Value      DOUBLE

First 3 rows:
  Iso3      Quintiles classes  \
0  VEN  Quintile 3: 40 to 60%
1  VCT  Quintile 3: 40 to 60%
2  USA  Quintile 1:  0 to 20%

                                       Causename Eng  \
0  Diabetes mellitus (excluding CKD due to Diabetes)
1  Diabetes mellitus (excluding CKD due to Diabetes)
2  Diabetes mellitus (excluding CKD due to Diabetes)

                       Location Name Measure Name En  Year  \
0  Venezuela, Bolivarian Republic of          Deaths  2019
1   Saint Vincent and the Grenadines          Deaths  2019
2           United States of America          Deaths  2019

   Latitude (generated)  Longitude (generated)  Value Low   Value Up  \
0                6.9830               -64.5880   30.33924  49.751212
1               13.2528               -61.1949   35.87554  50.156859
2               40.0792               -98.8164    8.34613   9.646632

       Value
0  39.291483
1  42.725138
2   9.115689

=== PAHO_SUMMARY ===
Rows: 66

Columns:
          column_name column_type
0  Year of Year dated      BIGINT
1   Indicator Name En     VARCHAR
2    % of Total Value     VARCHAR

First 3 rows:
   Year of Year dated                                  Indicator Name En  \
0                1990  Number of people aged 30+ years with diabetes ...
1                1991  Number of people aged 30+ years with diabetes ...
2                1992  Number of people aged 30+ years with diabetes ...

  % of Total Value
0        42.36717%
1        42.77484%
2        43.18176%

Diabetes_012 (CDC): Distribution
   Diabetes_012   count  percentage
0           0.0  216762       82.86
1           1.0    6581        2.52
2           2.0   38246       14.62

# 1.2.1. PAHO Prevalence: Convert Value, Value Low, Value High a float
con.execute("""
    UPDATE paho_prevalence
    SET
        Value = CAST(REPLACE(Value, '%', '') AS DOUBLE),
        "Value Low" = CAST(REPLACE("Value Low", '%', '') AS DOUBLE),
        "Value High" = CAST(REPLACE("Value High", '%', '') AS DOUBLE)
    WHERE Value IS NOT NULL
""")

# Verify that they converted
print("Example after cleaning (PAHO Prevalence):")
print(con.execute("""
    SELECT "Indicator Name En", Year, Value, "Value Low", "Value High"
    FROM paho_prevalence
    WHERE Year IN (2019, 2022)
    LIMIT 10
""").fetchdf())

# 1.2.2. Rename columns for consistency
# Example for CDC: all lowercase and replace spaces/camelCase
con.execute("""
    CREATE OR REPLACE TABLE cdc_clean AS
    SELECT
        Diabetes_012,
        KidneyDisease,
        HighBP,
        HighChol,
        CholCheck,
        Asthma,
        COPD,
        BMI,
        Smoker,
        Stroke,
        HeartDiseaseorAttack,
        PhysActivity,
        HvyAlcoholConsump,
        AnyHealthcare,
        NoDocbcCost,
        GenHlth,
        MentHlth,
        PhysHlth,
        DiffWalk,
        Sex,
        AgeGroup,
        Education,
        Income
    FROM cdc
""")

# For IDF (previously formatted, now rename)
con.execute("""
    ALTER TABLE idf RENAME COLUMN "Category" TO category;
    ALTER TABLE idf RENAME COLUMN "Metric" TO metric;
    ALTER TABLE idf RENAME COLUMN "Year" TO year;
    ALTER TABLE idf RENAME COLUMN "Value" TO value;
""")

# General check for missing values in CDC
print("\nMissing values in CDC:")
print(con.execute("""
    SELECT
        column_name,
        SUM(CASE WHEN column_name IS NULL THEN 1 ELSE 0 END) AS missing_count
    FROM
        (DESCRIBE cdc) AS cols
    CROSS JOIN
        (SELECT * FROM cdc LIMIT 1) AS sample
    GROUP BY column_name
""").fetchdf())  # Aproximate

print("\nAll looks clean and ready for EDA.")

Example after cleaning (PAHO Prevalence):
                                   Indicator Name En  Year  Value Value Low  \
0  Diabetes treatment coverage (current use of gl...  2019  56.28      53.2
1  Diabetes treatment coverage (current use of gl...  2022  57.71      53.3
2  Diabetes treatment coverage (current use of gl...  2019  56.72      52.2
3  Diabetes treatment coverage (current use of gl...  2022  57.83      51.5
4  Diabetes treatment coverage (current use of gl...  2019  55.89      51.2
5  Diabetes treatment coverage (current use of gl...  2022  57.65      50.9
6  Diabetes treatment coverage (current use of gl...  2019  57.57      54.4
7  Diabetes treatment coverage (current use of gl...  2022   59.3      54.9
8  Diabetes treatment coverage (current use of gl...  2019  58.13      53.6
9  Diabetes treatment coverage (current use of gl...  2022  59.51      53.1

  Value High
0       59.4
1       62.1
2       61.0
3       63.9
4       60.3
5       63.9
6       60.7
7       63.7
8       62.5
9       65.6

Missing values in CDC:
             column_name  missing_count
0                 HighBP            0.0
1               HighChol            0.0
2              CholCheck            0.0
3                   COPD            0.0
4               MentHlth            0.0
5                 Asthma            0.0
6                 Stroke            0.0
7               PhysHlth            0.0
8          AnyHealthcare            0.0
9               AgeGroup            0.0
10  HeartDiseaseorAttack            0.0
11     HvyAlcoholConsump            0.0
12           NoDocbcCost            0.0
13              DiffWalk            0.0
14          PhysActivity            0.0
15                Smoker            0.0
16          Diabetes_012            0.0
17                Income            0.0
18                   Sex            0.0
19             Education            0.0
20         KidneyDisease            0.0
21                   BMI            0.0
22               GenHlth            0.0

All looks clean and ready for EDA.

# 1.3.1. Clean PAHO Summary: convert % of Total Value to float
con.execute("""
    UPDATE paho_summary
    SET "% of Total Value" = CAST(REPLACE("% of Total Value", '%', '') AS DOUBLE)
    WHERE "% of Total Value" IS NOT NULL
""")

print("Example after cleaning PAHO Summary:")
print(con.execute("""
    SELECT "Year of Year dated", "Indicator Name En", "% of Total Value"
    FROM paho_summary
    WHERE "Year of Year dated" IN (2019, 2022)
""").fetchdf())

Example after cleaning PAHO Summary:
   Year of Year dated                                  Indicator Name En  \
0                2019  Number of people aged 30+ years with diabetes ...
1                2022  Number of people aged 30+ years with diabetes ...
2                2019  Number of people aged 30+ years with diabetes ...
3                2022  Number of people aged 30+ years with diabetes ...

  % of Total Value
0         57.56768
1         59.30143
2         42.43232
3         40.69857

# 1.3.2. Standardize column names (lowercase + underscores) for all tables
# This is to make queries easier and more consistent

# Function to rename columns in DuckDB
def standardize_columns(table_name):
    cols = con.execute(f"DESCRIBE {table_name}").fetchdf()['column_name'].tolist()
    for col in cols:
        new_col = col.lower().replace(' ', '_').replace('(', '').replace(')', '').replace('-', '_').replace('%', 'percent')
        if new_col != col:
            con.execute(f"ALTER TABLE {table_name} RENAME COLUMN \"{col}\" TO {new_col}")
    print(f"Standardized columns in {table_name}")

# Apply to all tables
for table in ['cdc', 'idf', 'paho_prevalence', 'paho_burden', 'paho_deaths_country', 'paho_summary']:
    standardize_columns(table)

# Quick check after standardization (example for one table)
print("\nCDC columns after standardization:")
print(con.execute("DESCRIBE cdc").fetchdf()[['column_name']])

print("\nAll tables are now clean and standardized. Ready for EDA!")

Standardized columns in cdc
Standardized columns in idf
Standardized columns in paho_prevalence
Standardized columns in paho_burden
Standardized columns in paho_deaths_country
Standardized columns in paho_summary

CDC columns after standardization:
             column_name
0           diabetes_012
1          kidneydisease
2                 highbp
3               highchol
4              cholcheck
5                 asthma
6                   copd
7                    bmi
8                 smoker
9                 stroke
10  heartdiseaseorattack
11          physactivity
12     hvyalcoholconsump
13         anyhealthcare
14           nodocbccost
15               genhlth
16              menthlth
17              physhlth
18              diffwalk
19                   sex
20              agegroup
21             education
22                income

All tables are now clean and standardized. Ready for EDA!

print("Final numeric conversion check & fix...")

def safe_convert_to_double(table, column):
    # Check current type
    current_type = con.execute(f"""
        SELECT column_type
        FROM (DESCRIBE {table})
        WHERE column_name = '{column}'
    """).fetchone()[0]

    if 'DOUBLE' in current_type.upper() or 'FLOAT' in current_type.upper():
        print(f"  {table}.{column} is already numeric ({current_type}) - skipping")
        return

    try:
        # Remove commas if present (only if still string)
        con.execute(f"""
            UPDATE {table}
            SET {column} = REPLACE({column}, ',', '')
            WHERE {column} IS NOT NULL
        """)

        # Convert to DOUBLE
        con.execute(f"""
            ALTER TABLE {table}
            ALTER COLUMN {column} SET DATA TYPE DOUBLE USING CAST({column} AS DOUBLE)
        """)
        print(f"  Converted {table}.{column} → DOUBLE")
    except Exception as e:
        print(f"  Warning on {table}.{column}: {e}")

# Apply to all relevant columns
tables_cols = [
    ('paho_prevalence', ['value', 'value_low', 'value_high']),
    ('paho_burden', ['value', 'value_low', 'value_up']),
    ('paho_summary', ['percent_of_total_value']),
    ('paho_deaths_country', ['value', 'value_low', 'value_up'])
]

for table, cols in tables_cols:
    for col in cols:
        safe_convert_to_double(table, col)

# Final check
print("\nFinal column types check:")
for table in ['paho_prevalence', 'paho_burden', 'paho_summary', 'paho_deaths_country']:
    print(f"\n{table.upper()}:")
    print(con.execute(f"DESCRIBE {table}").fetchdf()[['column_name', 'column_type']])

Final numeric conversion check & fix...
  Converted paho_prevalence.value → DOUBLE
  Converted paho_prevalence.value_low → DOUBLE
  Converted paho_prevalence.value_high → DOUBLE
  Converted paho_burden.value → DOUBLE
  Converted paho_burden.value_low → DOUBLE
  Converted paho_burden.value_up → DOUBLE
  Converted paho_summary.percent_of_total_value → DOUBLE
  paho_deaths_country.value is already numeric (DOUBLE) - skipping
  paho_deaths_country.value_low is already numeric (DOUBLE) - skipping
  paho_deaths_country.value_up is already numeric (DOUBLE) - skipping

Final column types check:

PAHO_PREVALENCE:
         column_name column_type
0      location_code     VARCHAR
1   location_name_en     VARCHAR
2  indicator_name_en     VARCHAR
3       age_group_en     VARCHAR
4             sex_en     VARCHAR
5               year      BIGINT
6              value      DOUBLE
7          value_low      DOUBLE
8         value_high      DOUBLE

PAHO_BURDEN:
        column_name column_type
0              iso3     VARCHAR
1     location_name     VARCHAR
2   amro_subregions     VARCHAR
3     causename_eng     VARCHAR
4              year      BIGINT
5               sex     VARCHAR
6         age_group     VARCHAR
7   measure_name_en     VARCHAR
8    metric_name_en     VARCHAR
9             value      DOUBLE
10        value_low      DOUBLE
11         value_up      DOUBLE

PAHO_SUMMARY:
              column_name column_type
0      year_of_year_dated      BIGINT
1       indicator_name_en     VARCHAR
2  percent_of_total_value      DOUBLE

PAHO_DEATHS_COUNTRY:
            column_name column_type
0                  iso3     VARCHAR
1     quintiles_classes     VARCHAR
2         causename_eng     VARCHAR
3         location_name     VARCHAR
4       measure_name_en     VARCHAR
5                  year      BIGINT
6    latitude_generated      DOUBLE
7   longitude_generated      DOUBLE
8             value_low      DOUBLE
9              value_up      DOUBLE
10                value      DOUBLE

# 2.1 Target Distribution

target_dist = con.execute("""
    SELECT
        diabetes_012,
        COUNT(*) AS count,
        ROUND(COUNT(*) * 100.0 / SUM(COUNT(*)) OVER (), 2) AS percentage
    FROM cdc
    GROUP BY diabetes_012
    ORDER BY diabetes_012
""").fetchdf()

# Map to readable labels
status_map = {0: 'No Diabetes', 1: 'Pre-diabetes', 2: 'Diabetes'}
target_dist['diabetes_status'] = target_dist['diabetes_012'].map(status_map)

fig_target = px.bar(
    target_dist,
    x='diabetes_status',
    y='percentage',
    color='diabetes_status',
    title='Diabetes Status Distribution (BRFSS 2023)',
    labels={'percentage': 'Percentage (%)'},
    color_discrete_map={
        'No Diabetes': '#1f77b4',
        'Pre-diabetes': '#ff7f0e',
        'Diabetes': '#2ca02c'
    },
    text='percentage'
)

fig_target.update_traces(texttemplate='%{text:.2f}%', textposition='outside')
fig_target.update_layout(
    yaxis_title='Percentage of Respondents (%)',
    xaxis_title='Diabetes Status',
    legend_title_text='Diabetes Status',
    showlegend=False   # Not needed since x-axis already has labels
)
fig_target.show()

# 2.2 Age Group Distribution

age_map = {
    1: '18-24', 2: '25-29', 3: '30-34', 4: '35-39',
    5: '40-44', 6: '45-49', 7: '50-54', 8: '55-59',
    9: '60-64', 10: '65-69', 11: '70-74', 12: '75-79', 13: '80+'
}

status_map = {0: 'No Diabetes', 1: 'Pre-diabetes', 2: 'Diabetes'}

age_diabetes = con.execute("""
    SELECT agegroup, diabetes_012, COUNT(*) AS count
    FROM cdc
    GROUP BY agegroup, diabetes_012
""").fetchdf()

age_diabetes['age_group_label'] = age_diabetes['agegroup'].map(age_map)
age_diabetes['diabetes_status'] = age_diabetes['diabetes_012'].map(status_map)
age_diabetes['percentage'] = age_diabetes.groupby('age_group_label')['count'].transform(lambda x: x / x.sum() * 100)

fig_age = px.bar(
    age_diabetes,
    x='age_group_label',
    y='percentage',
    color='diabetes_status',
    barmode='stack',
    title='Diabetes Status by Age Group',
    labels={'percentage': 'Percentage (%)', 'age_group_label': 'Age Group'},
    color_discrete_map={
        'No Diabetes': '#1f77b4',      # Blue
        'Pre-diabetes': '#ff7f0e',     # Orange
        'Diabetes': '#2ca02c'          # Green
    }
)

fig_age.update_layout(
    legend_title_text='Diabetes Status',
    yaxis_title='Percentage of People in Age Group (%)'
)
fig_age.update_xaxes(categoryorder='array', categoryarray=list(age_map.values()))
fig_age.show()

# 2.3 BMI Distribution by Diabetes Status

bmi_data = con.execute("""
    SELECT diabetes_012, bmi
    FROM cdc
    WHERE bmi IS NOT NULL
""").fetchdf()

status_map = {0: 'No Diabetes', 1: 'Pre-diabetes', 2: 'Diabetes'}
bmi_data['diabetes_status'] = bmi_data['diabetes_012'].map(status_map)

fig_bmi = px.box(
    bmi_data,
    x='diabetes_status',
    y='bmi',
    color='diabetes_status',
    title='BMI Distribution by Diabetes Status',
    labels={'bmi': 'Body Mass Index (BMI)', 'diabetes_status': 'Diabetes Status'},
    color_discrete_map={
        'No Diabetes': '#1f77b4',
        'Pre-diabetes': '#ff7f0e',
        'Diabetes': '#2ca02c'
    }
)

fig_bmi.update_layout(
    yaxis_title='Body Mass Index (BMI)',
    legend_title_text='Diabetes Status'
)
fig_bmi.show()

# 2.4 Quick look at PAHO prevalence trend (Americas)
print("\nDiabetes Prevalence Trend (Americas 18+ years, age-standardized):")
prevalence_trend = con.execute("""
    SELECT
        year,
        AVG(value) AS avg_prevalence_percent
    FROM paho_prevalence
    WHERE indicator_name_en LIKE '%Prevalence of diabetes in adults aged 18+ years%'
      AND "sex_en" = 'Both sexes'
      AND indicator_name_en LIKE '%age-standardized%'
    GROUP BY year
    ORDER BY year
""").fetchdf()

print(prevalence_trend)

fig_trend = px.line(
    prevalence_trend,
    x='year',
    y='avg_prevalence_percent',
    title='Diabetes Prevalence Trend in the Americas (18+, age-standardized)',
    markers=True
)
fig_trend.update_layout(yaxis_title='Prevalence (%)')
fig_trend.show()

Diabetes Prevalence Trend (Americas 18+ years, age-standardized):
   year  avg_prevalence_percent
0  1990                    7.06
1  1995                    7.83
2  2000                    8.51
3  2005                    9.41
4  2010                   10.57
5  2015                   11.53
6  2019                   12.32
7  2020                   12.55
8  2021                   12.80
9  2022                   13.06

# 2.5 High Blood Pressure by Diabetes Status

status_map = {0: 'No Diabetes', 1: 'Pre-diabetes', 2: 'Diabetes'}

highbp_diabetes = con.execute("""
    SELECT highbp, diabetes_012, COUNT(*) AS count
    FROM cdc
    GROUP BY highbp, diabetes_012
""").fetchdf()

highbp_diabetes['diabetes_status'] = highbp_diabetes['diabetes_012'].map(status_map)
highbp_diabetes['percentage'] = highbp_diabetes.groupby('highbp')['count'].transform(lambda x: x / x.sum() * 100)

fig_highbp = px.bar(
    highbp_diabetes,
    x='highbp',
    y='percentage',
    color='diabetes_status',
    barmode='stack',
    title='High Blood Pressure by Diabetes Status',
    labels={'highbp': 'High Blood Pressure', 'percentage': 'Percentage (%)'},
    color_discrete_map={
        'No Diabetes': '#1f77b4',
        'Pre-diabetes': '#ff7f0e',
        'Diabetes': '#2ca02c'
    }
)

fig_highbp.update_xaxes(tickvals=[0, 1], ticktext=['No', 'Yes'])
fig_highbp.update_layout(
    legend_title_text='Diabetes Status',
    yaxis_title='Percentage within each HighBP group (%)'
)
fig_highbp.show()

#2.6 General Health by Diabetes Status

status_map = {0: 'No Diabetes', 1: 'Pre-diabetes', 2: 'Diabetes'}

genhlth_diabetes = con.execute("""
    SELECT genhlth, diabetes_012, COUNT(*) AS count
    FROM cdc
    GROUP BY genhlth, diabetes_012
""").fetchdf()

genhlth_diabetes['diabetes_status'] = genhlth_diabetes['diabetes_012'].map(status_map)
genhlth_diabetes['percentage'] = genhlth_diabetes.groupby('genhlth')['count'].transform(lambda x: x / x.sum() * 100)

fig_genhlth = px.bar(
    genhlth_diabetes,
    x='genhlth',
    y='percentage',
    color='diabetes_status',
    barmode='stack',
    title='Self-Reported General Health by Diabetes Status',
    labels={'genhlth': 'General Health (1=Excellent → 5=Poor)', 'percentage': 'Percentage (%)'},
    color_discrete_map={
        'No Diabetes': '#1f77b4',
        'Pre-diabetes': '#ff7f0e',
        'Diabetes': '#2ca02c'
    }
)

fig_genhlth.update_layout(
    legend_title_text='Diabetes Status',
    yaxis_title='Percentage within each Health Rating (%)'
)
fig_genhlth.show()

# 2.7 Physical Activity by Diabetes Status

physact = con.execute("""
    SELECT physactivity, diabetes_012, COUNT(*) AS count
    FROM cdc
    GROUP BY physactivity, diabetes_012
""").fetchdf()

physact['percentage'] = physact.groupby('physactivity')['count'].transform(lambda x: x / x.sum() * 100)
physact['diabetes_status'] = physact['diabetes_012'].map(status_map)

fig_phys = px.bar(
    physact,
    x='physactivity',
    y='percentage',
    color='diabetes_status',
    barmode='stack',
    title='Physical Activity by Diabetes Status',
    labels={'physactivity': 'Physically Active', 'percentage': 'Percentage (%)'},
    color_discrete_map={'No Diabetes': '#1f77b4', 'Pre-diabetes': '#ff7f0e', 'Diabetes': '#2ca02c'}
)

fig_phys.update_xaxes(tickvals=[0, 1], ticktext=['No', 'Yes'])
fig_phys.update_layout(legend_title_text='Diabetes Status')
fig_phys.show()

# 2.8 Income Level by Diabetes Status
income_diabetes = con.execute("""
    SELECT income, diabetes_012, COUNT(*) AS count
    FROM cdc
    GROUP BY income, diabetes_012
""").fetchdf()

income_diabetes['percentage'] = income_diabetes.groupby('income')['count'].transform(lambda x: x / x.sum() * 100)
income_diabetes['diabetes_status'] = income_diabetes['diabetes_012'].map(status_map)

fig_income = px.bar(
    income_diabetes,
    x='income',
    y='percentage',
    color='diabetes_status',
    barmode='stack',
    title='Income Level by Diabetes Status',
    labels={'income': 'Income Level (1=Low → 8=High)', 'percentage': 'Percentage (%)'},
    color_discrete_map={'No Diabetes': '#1f77b4', 'Pre-diabetes': '#ff7f0e', 'Diabetes': '#2ca02c'}
)

fig_income.update_layout(legend_title_text='Diabetes Status')
fig_income.show()

# 2.9 Correlation Heatmap
numeric_cols = ['bmi', 'highbp', 'highchol', 'physactivity', 'genhlth',
                'menthlth', 'physhlth', 'diffwalk', 'agegroup', 'income']

corr_df = con.execute(f"SELECT {', '.join(numeric_cols)} FROM cdc").fetchdf().corr()

fig_corr = px.imshow(
    corr_df,
    text_auto='.2f',
    aspect="auto",
    color_continuous_scale='RdBu_r',
    title='Correlation Heatmap of Key Risk Factors'
)
fig_corr.update_layout(
    xaxis_title='Features',
    yaxis_title='Features'
)
fig_corr.show()

# 3.1 Create Clean Working Table

print("Creating clean working table 'diabetes_features' for engineering...")

con.execute("""
    CREATE OR REPLACE TABLE diabetes_features AS
    SELECT
        diabetes_012,
        bmi,
        highbp,
        highchol,
        cholcheck,
        smoker,
        stroke,
        heartdiseaseorattack,
        physactivity,
        hvyalcoholconsump,
        genhlth,
        menthlth,
        physhlth,
        diffwalk,
        sex,
        agegroup,
        education,
        income,
        kidneydisease,
        asthma,
        copd,
        anyhealthcare,
        nodocbccost
    FROM cdc
""")

print("Working table 'diabetes_features' created with",
      con.execute("SELECT COUNT(*) FROM diabetes_features").fetchone()[0], "rows")

Creating clean working table 'diabetes_features' for engineering...
Working table 'diabetes_features' created with 261589 rows

# 3.2 Feature Engineering

print("Starting feature engineering...")

con.execute("""
    CREATE OR REPLACE TABLE diabetes_features AS
    SELECT
        *,

        -- 1. Age Groups (clinically meaningful)
        CASE
            WHEN agegroup <= 5 THEN 'Young Adult (18-44)'
            WHEN agegroup <= 8 THEN 'Middle Aged (45-59)'
            WHEN agegroup <= 11 THEN 'Senior (60-74)'
            ELSE 'Elderly (75+)'
        END AS age_group_cat,

        -- 2. BMI Categories (WHO standard)
        CASE
            WHEN bmi < 18.5 THEN 'Underweight'
            WHEN bmi < 25.0 THEN 'Normal'
            WHEN bmi < 30.0 THEN 'Overweight'
            WHEN bmi < 35.0 THEN 'Obese Class I'
            WHEN bmi < 40.0 THEN 'Obese Class II'
            ELSE 'Obese Class III'
        END AS bmi_category,

        -- 3. Comorbidity Count
        (highbp + highchol + kidneydisease + stroke + heartdiseaseorattack + asthma + copd)::INTEGER AS comorbidity_count,

        -- 4. Risk Score (simple additive)
        (highbp + highchol + (bmi >= 30)::INTEGER + (physactivity = 0)::INTEGER +
         (genhlth >= 4)::INTEGER + (diffwalk = 1)::INTEGER)::INTEGER AS diabetes_risk_score,

        -- 5. Age + BMI Interaction (high risk combination)
        CASE
            WHEN agegroup >= 9 AND bmi >= 30 THEN 'High Risk: Senior + Obese'
            WHEN agegroup >= 7 AND bmi >= 30 THEN 'Moderate Risk: Middle-age + Obese'
            ELSE 'Standard Risk'
        END AS age_bmi_risk_group,

        -- 6. Lifestyle Score (higher = better)
        (physactivity + (hvyalcoholconsump = 0)::INTEGER + (smoker = 0)::INTEGER)::INTEGER AS lifestyle_score

    FROM diabetes_features
""")

print("Feature engineering completed. New features added.")
print("\nSample of engineered features:")
print(con.execute("""
    SELECT diabetes_012, age_group_cat, bmi_category, comorbidity_count,
           diabetes_risk_score, age_bmi_risk_group, lifestyle_score
    FROM diabetes_features
    LIMIT 8
""").fetchdf())

Starting feature engineering...
Feature engineering completed. New features added.

Sample of engineered features:
   diabetes_012        age_group_cat     bmi_category  comorbidity_count  \
0           0.0        Elderly (75+)           Normal                  7
1           2.0        Elderly (75+)       Overweight                  7
2           0.0       Senior (60-74)    Obese Class I                  8
3           0.0        Elderly (75+)    Obese Class I                  7
4           2.0        Elderly (75+)           Normal                  9
5           0.0  Middle Aged (45-59)  Obese Class III                  8
6           0.0       Senior (60-74)    Obese Class I                  6
7           0.0        Elderly (75+)           Normal                  6

   diabetes_risk_score                 age_bmi_risk_group  lifestyle_score
0                    4                      Standard Risk                2
1                    3                      Standard Risk                3
2                    3          High Risk: Senior + Obese                3
3                    5          High Risk: Senior + Obese                2
4                    2                      Standard Risk                2
5                    3  Moderate Risk: Middle-age + Obese                3
6                    2          High Risk: Senior + Obese                2
7                    1                      Standard Risk                1

# 3.3 Feature Exploration

print("=== Feature Exploration: New Variables vs Diabetes Status ===\n")

# 1. Age Group Category vs Diabetes Prevalence
print("1. Age Group Category vs Diabetes Prevalence:")
print(con.execute("""
    SELECT
        age_group_cat,
        COUNT(*) AS total_count,
        SUM(CASE WHEN diabetes_012 = 2 THEN 1 ELSE 0 END) AS diabetes_cases,
        ROUND(100.0 * SUM(CASE WHEN diabetes_012 = 2 THEN 1 ELSE 0 END) / COUNT(*), 2) AS diabetes_pct
    FROM diabetes_features
    GROUP BY age_group_cat
    ORDER BY diabetes_pct DESC
""").fetchdf())

# 2. BMI Category vs Diabetes Prevalence
print("\n2. BMI Category vs Diabetes Prevalence:")
print(con.execute("""
    SELECT
        bmi_category,
        COUNT(*) AS total_count,
        SUM(CASE WHEN diabetes_012 = 2 THEN 1 ELSE 0 END) AS diabetes_cases,
        ROUND(100.0 * SUM(CASE WHEN diabetes_012 = 2 THEN 1 ELSE 0 END) / COUNT(*), 2) AS diabetes_pct
    FROM diabetes_features
    GROUP BY bmi_category
    ORDER BY
        CASE bmi_category
            WHEN 'Underweight' THEN 1
            WHEN 'Normal' THEN 2
            WHEN 'Overweight' THEN 3
            WHEN 'Obese Class I' THEN 4
            WHEN 'Obese Class II' THEN 5
            WHEN 'Obese Class III' THEN 6
        END
""").fetchdf())

# 3. Comorbidity Count and Risk Score by Diabetes Status
print("\n3. Average Comorbidities and Risk Score by Diabetes Status:")
print(con.execute("""
    SELECT
        diabetes_012,
        ROUND(AVG(comorbidity_count), 2) AS avg_comorbidities,
        ROUND(AVG(diabetes_risk_score), 2) AS avg_risk_score,
        ROUND(AVG(lifestyle_score), 2) AS avg_lifestyle_score
    FROM diabetes_features
    GROUP BY diabetes_012
    ORDER BY diabetes_012
""").fetchdf())

# 4. High-Risk Age + BMI Groups
print("\n4. Age + BMI Risk Groups vs Diabetes Prevalence:")
print(con.execute("""
    SELECT
        age_bmi_risk_group,
        COUNT(*) AS total_count,
        ROUND(100.0 * SUM(CASE WHEN diabetes_012 = 2 THEN 1 ELSE 0 END) / COUNT(*), 2) AS diabetes_pct
    FROM diabetes_features
    GROUP BY age_bmi_risk_group
    ORDER BY diabetes_pct DESC
""").fetchdf())

=== Feature Exploration: New Variables vs Diabetes Status ===

1. Age Group Category vs Diabetes Prevalence:
         age_group_cat  total_count  diabetes_cases  diabetes_pct
0        Elderly (75+)        42191          8990.0         21.31
1       Senior (60-74)        88039         17700.0         20.10
2  Middle Aged (45-59)        64257          8824.0         13.73
3  Young Adult (18-44)        67102          2732.0          4.07

2. BMI Category vs Diabetes Prevalence:
      bmi_category  total_count  diabetes_cases  diabetes_pct
0      Underweight         3495           208.0          5.95
1           Normal        64682          4464.0          6.90
2       Overweight        93432         11392.0         12.19
3    Obese Class I        58433         11045.0         18.90
4   Obese Class II        24696          6079.0         24.62
5  Obese Class III        16851          5058.0         30.02

3. Average Comorbidities and Risk Score by Diabetes Status:
   diabetes_012  avg_comorbidities  avg_risk_score  avg_lifestyle_score
0           0.0               6.64            1.54                 2.35
1           1.0               7.08            2.53                 2.22
2           2.0               7.28            3.06                 2.13

4. Age + BMI Risk Groups vs Diabetes Prevalence:
                  age_bmi_risk_group  total_count  diabetes_pct
0          High Risk: Senior + Obese        46214         30.81
1  Moderate Risk: Middle-age + Obese        20456         23.27
2                      Standard Risk       194919          9.88

# 3.5 Create Final Modeling Table

print("Creating final modeling table...")

con.execute("""
    CREATE OR REPLACE TABLE diabetes_model_ready AS
    SELECT
        diabetes_012 AS target,

        -- Original features
        bmi,
        highbp,
        highchol,
        physactivity,
        genhlth,
        diffwalk,
        agegroup,
        income,
        sex,

        -- Engineered features
        age_group_cat,
        bmi_category,
        comorbidity_count,
        diabetes_risk_score,
        age_bmi_risk_group,
        lifestyle_score,

        -- One-hot / dummy ready (we'll use these in modeling)
        CASE WHEN bmi_category = 'Obese Class III' THEN 1 ELSE 0 END AS obese_class_iii,
        CASE WHEN age_group_cat IN ('Senior (60-74)', 'Elderly (75+)') THEN 1 ELSE 0 END AS senior_or_elderly,
        CASE WHEN highbp = 1 AND highchol = 1 THEN 1 ELSE 0 END AS has_metabolic_risk

    FROM diabetes_features
""")

print("Final modeling table 'diabetes_model_ready' created with",
      con.execute("SELECT COUNT(*) FROM diabetes_model_ready").fetchone()[0], "rows")
print("\nColumns ready for modeling:")
print(con.execute("DESCRIBE diabetes_model_ready").fetchdf()['column_name'].tolist())

Creating final modeling table...
Final modeling table 'diabetes_model_ready' created with 261589 rows

Columns ready for modeling:
['target', 'bmi', 'highbp', 'highchol', 'physactivity', 'genhlth', 'diffwalk', 'agegroup', 'income', 'sex', 'age_group_cat', 'bmi_category', 'comorbidity_count', 'diabetes_risk_score', 'age_bmi_risk_group', 'lifestyle_score', 'obese_class_iii', 'senior_or_elderly', 'has_metabolic_risk']

# 4.1.1 Data Preparation for Multi-class modeling

from sklearn.model_selection import train_test_split

print("=== Preparing Data for Modeling ===\n")

# 1. Load the table
df = con.execute("SELECT * FROM diabetes_model_ready").fetchdf()

# 2. One-Hot Encode all categorical columns
categorical_cols = ['age_group_cat', 'bmi_category', 'age_bmi_risk_group']

df_encoded = pd.get_dummies(df, columns=categorical_cols, drop_first=True)

print(f"Shape after One-Hot Encoding: {df_encoded.shape}")
print(f"Categorical columns encoded: {categorical_cols}")

# 3. Prepare X and y
X = df_encoded.drop(columns=['target'])
y = df_encoded['target']

# 4. Train-Test Split
X_train, X_test, y_train, y_test = train_test_split(
    X, y, test_size=0.20, random_state=42, stratify=y
)

print(f"Training samples: {X_train.shape[0]:,}")
print(f"Test samples: {X_test.shape[0]:,}")

print(f"Class distribution in training set:\n{y_train.value_counts(normalize=True).round(4)*100}")

=== Preparing Data for Modeling ===

Shape after One-Hot Encoding: (261589, 26)
Categorical columns encoded: ['age_group_cat', 'bmi_category', 'age_bmi_risk_group']
Training samples: 209,271
Test samples: 52,318
Class distribution in training set:
target
0.0    82.86
2.0    14.62
1.0     2.52
Name: proportion, dtype: float64

# 4.1.2 Multi-class Modeling (Logistic Regression + Random Forest + XGBoost)

from sklearn.linear_model import LogisticRegression
from sklearn.ensemble import RandomForestClassifier
from xgboost import XGBClassifier
from sklearn.metrics import classification_report, confusion_matrix, f1_score

print("=== Training Multiple Models ===\n")

models = {
    "Logistic Regression": LogisticRegression(max_iter=1000, class_weight='balanced', random_state=42, n_jobs=-1),
    "Random Forest": RandomForestClassifier(n_estimators=300, class_weight='balanced', random_state=42, n_jobs=-1),
    "XGBoost": XGBClassifier(n_estimators=300, learning_rate=0.1, max_depth=6,
                             subsample=0.8, colsample_bytree=0.8, random_state=42,
                             eval_metric='mlogloss', n_jobs=-1)
}

for name, model in models.items():
    print(f"Training {name}...")
    model.fit(X_train, y_train)
    y_pred = model.predict(X_test)

    print(f"\n{name} Classification Report:")
    print(classification_report(y_test, y_pred, digits=4))

    # F1-score for diabetes class (class 2) - most important metric
    f1_diabetes = f1_score(y_test, y_pred, labels=[2], average='macro')
    print(f"F1-score for Diabetes class (2): {f1_diabetes:.4f}")
    print("-" * 60)

=== Training Multiple Models ===

Training Logistic Regression...

Logistic Regression Classification Report:
              precision    recall  f1-score   support

         0.0     0.9421    0.6324    0.7568     43353
         1.0     0.0386    0.2682    0.0674      1316
         2.0     0.3354    0.6168    0.4345      7649

    accuracy                         0.6210     52318
   macro avg     0.4387    0.5058    0.4196     52318
weighted avg     0.8307    0.6210    0.6923     52318

F1-score for Diabetes class (2): 0.4345
------------------------------------------------------------
Training Random Forest...

Random Forest Classification Report:
              precision    recall  f1-score   support

         0.0     0.8552    0.8912    0.8728     43353
         1.0     0.0255    0.0236    0.0245      1316
         2.0     0.3361    0.2603    0.2934      7649

    accuracy                         0.7771     52318
   macro avg     0.4056    0.3917    0.3969     52318
weighted avg     0.7584    0.7771    0.7668     52318

F1-score for Diabetes class (2): 0.2934
------------------------------------------------------------
Training XGBoost...

XGBoost Classification Report:
              precision    recall  f1-score   support

         0.0     0.8488    0.9783    0.9090     43353
         1.0     0.0000    0.0000    0.0000      1316
         2.0     0.5544    0.1700    0.2602      7649

    accuracy                         0.8355     52318
   macro avg     0.4677    0.3828    0.3897     52318
weighted avg     0.7844    0.8355    0.7912     52318

F1-score for Diabetes class (2): 0.2602
------------------------------------------------------------

# 4.2.1 Binary Classification: No Diabetes vs Any Diabetes Risk

print("=== Binary Classification: No Diabetes vs Any Diabetes Risk ===\n")

# Load fresh data
df = con.execute("SELECT * FROM diabetes_model_ready").fetchdf()

# Create binary target
df['target_binary'] = df['target'].apply(lambda x: 0 if x == 0 else 1)

# One-Hot Encoding for categorical columns
categorical_cols = ['age_group_cat', 'bmi_category', 'age_bmi_risk_group']
df_encoded = pd.get_dummies(df, columns=categorical_cols, drop_first=True)

X = df_encoded.drop(columns=['target', 'target_binary'])
y = df_encoded['target_binary']

# Train-test split
X_train, X_test, y_train, y_test = train_test_split(
    X, y, test_size=0.20, random_state=42, stratify=y
)

print(f"Training samples: {X_train.shape[0]:,}")
print(f"Test samples: {X_test.shape[0]:,}")
print(f"Positive class (Any diabetes risk) percentage: {y.mean():.2%}\n")

=== Binary Classification: No Diabetes vs Any Diabetes Risk ===

Training samples: 209,271
Test samples: 52,318
Positive class (Any diabetes risk) percentage: 17.14%

# 4.2.2.1 Logistic Regression

print("Training Logistic Regression (Binary)...")
model_lr = LogisticRegression(max_iter=1000, class_weight='balanced', random_state=42, n_jobs=-1)
model_lr.fit(X_train, y_train)
y_pred_lr = model_lr.predict(X_test)

print("Logistic Regression Results:")
print(classification_report(y_test, y_pred_lr, digits=4))

Training Logistic Regression (Binary)...
Logistic Regression Results:
              precision    recall  f1-score   support

           0     0.9329    0.7014    0.8007     43353
           1     0.3436    0.7561    0.4725      8965

    accuracy                         0.7107     52318
   macro avg     0.6383    0.7287    0.6366     52318
weighted avg     0.8319    0.7107    0.7445     52318

# 4.2.2.2 Random Forest

print("\nTraining Random Forest (Binary)...")
model_rf = RandomForestClassifier(n_estimators=300, class_weight='balanced', random_state=42, n_jobs=-1)
model_rf.fit(X_train, y_train)
y_pred_rf = model_rf.predict(X_test)

print("Random Forest Results:")
print(classification_report(y_test, y_pred_rf, digits=4))

Training Random Forest (Binary)...
Random Forest Results:
              precision    recall  f1-score   support

           0     0.8591    0.8956    0.8770     43353
           1     0.3646    0.2898    0.3229      8965

    accuracy                         0.7918     52318
   macro avg     0.6119    0.5927    0.6000     52318
weighted avg     0.7744    0.7918    0.7820     52318

# 4.2.2.3 XGBoost

print("\nTraining XGBoost (Binary)...")
model_xgb = XGBClassifier(
    n_estimators=300,
    learning_rate=0.1,
    max_depth=6,
    subsample=0.8,
    colsample_bytree=0.8,
    random_state=42,
    eval_metric='logloss',
    n_jobs=-1
)
model_xgb.fit(X_train, y_train)
y_pred_xgb = model_xgb.predict(X_test)

print("XGBoost Results:")
print(classification_report(y_test, y_pred_xgb, digits=4))

Training XGBoost (Binary)...
XGBoost Results:
              precision    recall  f1-score   support

           0     0.8517    0.9716    0.9077     43353
           1     0.5694    0.1816    0.2754      8965

    accuracy                         0.8362     52318
   macro avg     0.7105    0.5766    0.5915     52318
weighted avg     0.8033    0.8362    0.7993     52318

# 4.2.4 Feature Importance (XGBoost)

# Get feature importance from XGBoost
importances = model_xgb.feature_importances_
feature_names = X_train.columns

feat_imp = pd.DataFrame({
    'feature': feature_names,
    'importance': importances
}).sort_values('importance', ascending=False).head(15)

print("Top 15 Most Important Features (XGBoost):")
print(feat_imp)

# Plot
plt.figure(figsize=(10, 8))
plt.barh(feat_imp['feature'], feat_imp['importance'])
plt.xlabel('Importance Score')
plt.title('Top 15 Feature Importance - XGBoost Model')
plt.gca().invert_yaxis()
plt.tight_layout()
plt.show()

Top 15 Most Important Features (XGBoost):
                              feature  importance
10                diabetes_risk_score    0.368261
17  age_group_cat_Young Adult (18-44)    0.081003
13                  senior_or_elderly    0.068727
4                             genhlth    0.053791
24   age_bmi_risk_group_Standard Risk    0.049790
6                            agegroup    0.037466
14                 has_metabolic_risk    0.036997
20       bmi_category_Obese Class III    0.032434
1                              highbp    0.030059
3                        physactivity    0.022631
8                                 sex    0.021122
12                    obese_class_iii    0.021052
18         bmi_category_Obese Class I    0.018625
11                    lifestyle_score    0.016660
0                                 bmi    0.016236

# 4.2.5 Model Demonstration with Example Patients

print("=== Model Demonstration with Example Patients ===\n")
print("Using Logistic Regression (best recall model)\n")

# Create realistic patient profiles
examples = pd.DataFrame({
    'bmi': [22.5, 27.8, 28.0, 34.5, 31.2],
    'highbp': [0, 0, 1, 1, 1],
    'highchol': [0, 0, 0, 1, 1],
    'physactivity': [1, 0, 1, 0, 0],
    'genhlth': [2, 3, 3, 4, 4],
    'diffwalk': [0, 0, 0, 1, 0],
    'agegroup': [4, 5, 8, 11, 10],
    'income': [6, 7, 4, 3, 5],
    'sex': [0, 1, 1, 0, 1],

    'age_group_cat': ['Young Adult (18-44)', 'Young Adult (18-44)',
                      'Middle Aged (45-59)', 'Senior (60-74)', 'Senior (60-74)'],
    'bmi_category': ['Normal', 'Overweight', 'Overweight',
                     'Obese Class I', 'Obese Class I'],
    'comorbidity_count': [1, 2, 2, 5, 4],
    'diabetes_risk_score': [2, 5, 4, 7, 6],
    'age_bmi_risk_group': ['Standard Risk', 'Standard Risk',
                           'Standard Risk', 'High Risk: Senior + Obese',
                           'Moderate Risk: Middle-age + Obese'],
    'lifestyle_score': [3, 1, 2, 1, 2],
    'obese_class_iii': [0, 0, 0, 0, 0],
    'senior_or_elderly': [0, 0, 0, 1, 1],
    'has_metabolic_risk': [0, 0, 0, 1, 1]
})

# One-hot encode
examples_encoded = pd.get_dummies(examples,
                                  columns=['age_group_cat', 'bmi_category', 'age_bmi_risk_group'],
                                  drop_first=True)

for col in X_train.columns:
    if col not in examples_encoded.columns:
        examples_encoded[col] = 0

examples_encoded = examples_encoded[X_train.columns]

# Predictions
probabilities = model_lr.predict_proba(examples_encoded)[:, 1]
predictions = model_lr.predict(examples_encoded)

# Display
demo_results = examples.copy()
demo_results['Predicted Risk'] = ['Low Risk' if p == 0 else 'High Risk' for p in predictions]
demo_results['Risk Probability (%)'] = (probabilities * 100).round(1)

print(demo_results[[
    'age_group_cat',
    'bmi_category',
    'genhlth',
    'highbp',
    'physactivity',
    'Predicted Risk',
    'Risk Probability (%)'
]].to_string(index=False))

=== Model Demonstration with Example Patients ===

Using Logistic Regression (best recall model)

      age_group_cat  bmi_category  genhlth  highbp  physactivity Predicted Risk  Risk Probability (%)
Young Adult (18-44)        Normal        2       0             1       Low Risk                   4.9
Young Adult (18-44)    Overweight        3       0             0       Low Risk                  12.6
Middle Aged (45-59)    Overweight        3       1             1      High Risk                  63.6
     Senior (60-74) Obese Class I        4       1             0      High Risk                  87.1
     Senior (60-74) Obese Class I        4       1             0      High Risk                  86.7

# 5.1 Choosing the Number of Clusters - Clustering & Population Segmentation

from sklearn.cluster import KMeans
from sklearn.preprocessing import StandardScaler
import plotly.express as px

print("=== Clustering Analysis ===\n")

# Select features for clustering (numeric + encoded)
cluster_features = ['bmi', 'agegroup', 'genhlth', 'highbp', 'highchol',
                    'physactivity', 'comorbidity_count', 'diabetes_risk_score',
                    'lifestyle_score', 'senior_or_elderly', 'has_metabolic_risk']

X_cluster = X[cluster_features].copy()   # Using the encoded X from previous section

# Standardize the data (this is important for K-Means)
scaler = StandardScaler()
X_scaled = scaler.fit_transform(X_cluster)

# Determine optimal number of clusters using Elbow method
inertia = []
for k in range(1, 10):
    kmeans = KMeans(n_clusters=k, random_state=42, n_init=10)
    kmeans.fit(X_scaled)
    inertia.append(kmeans.inertia_)

fig_elbow = px.line(x=range(1,10), y=inertia, markers=True,
                    title='Elbow Method for Optimal Number of Clusters',
                    labels={'x': 'Number of Clusters (k)', 'y': 'Inertia'})
fig_elbow.show()

# Choose k=4 based on elbow + interpretability
kmeans = KMeans(n_clusters=4, random_state=42, n_init=10)
clusters = kmeans.fit_predict(X_scaled)

# Add cluster labels to the original dataframe
df_clustered = df_encoded.copy()
df_clustered['cluster'] = clusters

print("Cluster distribution:")
print(df_clustered['cluster'].value_counts().sort_index())

# Analyze clusters: Mean values per cluster
cluster_profile = df_clustered.groupby('cluster').mean().round(2)
print("\nCluster Profiles (mean values):")
print(cluster_profile[['bmi', 'agegroup', 'genhlth', 'highbp', 'comorbidity_count',
                       'diabetes_risk_score', 'lifestyle_score', 'target']])

=== Clustering Analysis ===

Cluster distribution:
cluster
0    95187
1    66017
2    37846
3    62539
Name: count, dtype: int64

Cluster Profiles (mean values):
           bmi  agegroup  genhlth  highbp  comorbidity_count  \
cluster
0        28.19      4.89     2.26    0.15               6.18
1        30.33      9.72     2.97    1.00               7.97
2        30.88      8.37     3.10    0.35               6.39
3        26.96     10.67     2.33    0.31               6.51

         diabetes_risk_score  lifestyle_score  target
cluster
0                       0.81             2.61    0.10
1                       3.33             2.16    0.64
2                       2.73             1.46    0.39
3                       1.08             2.55    0.26

# 5.3 Cluster Profiles and Interpretation - Visualization

# Create a clean summary for plotting
viz_data = pd.DataFrame({
    'Cluster Profile': [
        '0: Low Risk (Young, healthy)',
        '1: Very High Risk (Older, obese, comorbidities)',
        '2: High Risk (Obese, poor health)',
        '3: Moderate Risk (Older, moderate BMI)'
    ],
    'Diabetes Prevalence (%)': [10.0, 64.0, 39.0, 26.0],
    'Size (n)': [95187, 66017, 37846, 62539]
})

fig = px.bar(
    viz_data,
    x='Cluster Profile',
    y='Diabetes Prevalence (%)',
    text='Diabetes Prevalence (%)',
    title='Diabetes Prevalence by Population Segment',
    color='Cluster Profile',
    color_discrete_sequence=['#2ca02c', '#d62728', '#ff7f0e', '#1f77b4']
)

fig.update_traces(texttemplate='%{text:.1f}%', textposition='outside')
fig.update_layout(
    yaxis_title='Diabetes Prevalence (%)',
    xaxis_title='Cluster Profile',
    showlegend=False,
    height=550
)
fig.show()

# ======================================
# Export data for Streamlit Dashboard
# ======================================

# load the final table
con.execute("""
    CREATE OR REPLACE TABLE diabetes_model_ready AS
    SELECT * FROM diabetes_features
""")

# Export it to parquet
df_model_ready = con.execute("SELECT * FROM diabetes_model_ready").fetchdf()

# Save as parquet
df_model_ready.to_parquet("data/diabetes_model_ready.parquet", index=False)

print("✅ Successfully saved 'data/diabetes_model_ready.parquet'")
print(f"Shape: {df_model_ready.shape}")
print("Columns:", df_model_ready.columns.tolist())

✅ Successfully saved 'data/diabetes_model_ready.parquet'
Shape: (261589, 29)
Columns: ['diabetes_012', 'bmi', 'highbp', 'highchol', 'cholcheck', 'smoker', 'stroke', 'heartdiseaseorattack', 'physactivity', 'hvyalcoholconsump', 'genhlth', 'menthlth', 'physhlth', 'diffwalk', 'sex', 'agegroup', 'education', 'income', 'kidneydisease', 'asthma', 'copd', 'anyhealthcare', 'nodocbccost', 'age_group_cat', 'bmi_category', 'comorbidity_count', 'diabetes_risk_score', 'age_bmi_risk_group', 'lifestyle_score']

# ======================================
# Save the trained model for Streamlit
# ======================================

import joblib
import os

# Create the models folder if it doesn't exist
os.makedirs("models", exist_ok=True)

# Save the model
joblib.dump(model_lr, "models/logistic_regression_model.pkl")

print("✅ Model saved successfully as 'models/logistic_regression_model.pkl'")
print("Folder 'models' created if it didn't exist.")

✅ Model saved successfully as 'models/logistic_regression_model.pkl'
Folder 'models' created if it didn't exist.

# Save the list of columns the model expects
import json

model_columns = list(X_train.columns)
with open("models/model_columns.json", "w") as f:
    json.dump(model_columns, f)

print("✅ Model columns saved as 'models/model_columns.json'")

✅ Model columns saved as 'models/model_columns.json'

Cluster	Número de Personas	Características Principales	Prevalencia de Diabetes (%)	Nivel de Riesgo	Recomendación
0	95,187	Adultos jóvenes, peso normal, buena salud general, pocas comorbilidades	10.0%	Bajo Riesgo	Prevención general
1	66,017	Adultos mayores, alto IMC, hipertensión, múltiples comorbilidades	64.0%	Riesgo Muy Alto	Tamizaje prioritario e intervención intensiva
2	37,846	Mediana edad a mayores, obesos, mala salud auto-reportada	39.0%	Alto Riesgo	Programas de estilo de vida dirigidos
3	62,539	Adultos mayores, IMC moderado, algunas comorbilidades	26.0%	Riesgo Moderado	Educación preventiva y monitoreo regular

Indicador	Valor 2024	Proyección 2050	Observación
Prevalencia estandarizada por edad	10.1%	11.5%	Se espera aumento constante
Personas con diabetes	35.4 millones	51.5 millones	+45% de crecimiento proyectado
Diabetes no diagnosticada	~30.4%	-	Alta carga oculta
Cobertura de tratamiento (Américas, 30+ años)	~57–59%	-	Brecha significativa de tratamiento

Análisis de Riesgo de Diabetes e Insights de Salud Pública¶

Descripción del Proyecto¶

Conjuntos de Datos¶

Objetivos¶

Objetivos Principales¶

Metas Técnicas¶

Tabla de Contenidos¶

1. Preparación y Limpieza de Datos

1.1. Preparación de Datos

1.2. Limpieza Inicial de Datos

1.3. Limpieza Final de Datos y Estandarización

1.4. Conversión Final a Tipo Numérico

2. Análisis Exploratorio de Datos (EDA)

2.1. Análisis Visual

2.2. Principales Insights y Conclusiones

1. Distribución de la Variable Objetivo

2. Factores de Riesgo Más Fuertes

3. Patrones Socioeconómicos

4. Contexto de América Latina

5. Principales Conclusiones para la Salud Pública

3. Ingeniería de Características y SQL Avanzado

3.1. Creación de una Tabla de Trabajo

3.2. Ingeniería de Características

3.3. Exploración de Características

3.4. Resumen de Ingeniería de Características

3.5. Creación de la Tabla Final para Modelado

4. Modelado Predictivo

Objetivos

4.1. Enfoque Multiclase (Intento Inicial)

4.2. Clasificación Binaria (Enfoque Final)

4.2.1. Preparación de Datos para Clasificación Binaria

4.2.2. Resultados del Modelado

4.2.3. Comparación de Modelos

4.2.4. Análisis de Importancia de Características

4.2.5. Demostración del Modelo con Pacientes Ejemplo

5. Clustering y Segmentación Poblacional

5.1. Elección del Número de Clusters

5.2. Análisis de Clusters

5.3. Perfiles de Clusters e Interpretación

6. Contexto Latam y Comparaciones

6.1. Indicadores Clave de Latam (Sudamérica y Centroamérica)

6.2. Comparación: Datos de EE.UU. vs Contexto Latam

6.3. Implicaciones para Argentina y América Latina

7. Conclusiones y Recomendaciones

7.1. Resumen del Proyecto

7.2. Hallazgos Clave

7.3. Recomendaciones

7.4. Limitaciones y Trabajo Futuro

8. Dashboard Streamlit

🚀 Dashboard Interactivo

Capturas de Pantalla de la App
